Description
SERIES
AH Series
MODEL
AH T600
CASE TYPE
Full Tower
DIMENSION (H X W X D)
628.3 x 337 x 763 mm
(27.74 x 13.3 x 30 inch)
NET WEIGHT
20.64 kg / 45.5 lb
SIDE PANEL
5mm Tempered Glass x 2
COLOR
Exterior & Interior : Black
MATERIAL
SPCC
DRIVE BAYS
-ACCESSIBLE
-HIDDEN
2 x 3.5″ or 3 x 2.5”
–
EXPANSION SLOTS
8
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 10.5” (E-ATX)
I/O PORT
1 x USB 3.1 (Gen 2) Type C, USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm
3 x 140mm or 2 x 140mm or 1 x 140mm
Top:
3 x 120mm or 2 x 120mm or 1 x 120mm
2 x 140mm or 1 x 140mm
Right:
3 x 120mm or 2 x 120mm or 1 x 120mm
2 x 140mm or 1 x 140mm
RADIATOR SUPPORT
Front:
1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 420mm or 1 x 280mm or 1 x 140mm
Top:
1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 280mm or 1 x 140mm
Right:
1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 280mm or 1 x 140mm
CLEARANCE
CPU cooler height limitation: 195mm
VGA length limitation: 300mm(With Water Pump)
440mm(Without Water Pump)
PSU length limitation: 200mm
